Marantz Model 30

34.990kr

Integrert forsterker i ny drakt fra Marantz

2x100W i 8ohm og 2x200W i 4ohm
Marantz HDAM-teknologi
Strålende RIIA-trinn for både MM- og MC-pickuper
Nøye utvalgte komponenter

Produktnr: I/A Kategori: Integrerte forsterkere

MASTER-TUNED INTEGRATED AMPLIFIER WITH CUSTOM-DESIGNED HDAM

Get the most musical sound possible from this Master-tuned integrated amplifier. Its custom-designed HDAM delivers exquisite detail and unforgettable musicality from any style of music.

Designed To Last
You see and feel it in the build quality and you hear it every time. No matter your musical passions, your music always sounds better with MODEL 30.
Tuned With Passion
Hundreds of hours of thoughtful Sound Master tuning ensure the exquisite detail and musicality Marantz always delivers.
Fully Discrete And Accurate Detailing
Marantz HDAM-SA3 technology is comprised of dozens of independent parts, each hand-selected for pure, detailed Marantz sound.
Extraordinary Sensitivity
Designed to replicate the sensitivity and feel of a vintage analog amplifier even when simply adjusting the volume.

FARGE	Gull, Sort, Sølv
INNGANGER	RCA
UTGANGER	RCA
TYPER	Transistor

Spesifikasjoner

Output Power

Rated Output Power	100W + 100W (8ohm) 200W + 200W (4ohm)
JEITA Power output	No

Features

Amplifier Circuit	Switching Amp (Hypex NC500/SMPS600 by single)
Power Trans	Toroidal w/case
Volume	Electric
Loudness	No
Bass / Treble / Mid / Balance Control	yes / yes / No / yes
REC Out Select	No
Source Direct	yes
Pure Direct	No
(Marantz) Purest Mode	No
Isolator (for USB-B input)	No
Jitter reducer	No
Dual Clock: 44.1 / 48 kHz	No
Digital Filter	No
Analog Amp Mode	No
Wide Range	5Hz – 50kHz
Total Harmonic Distortion	0.005% (1kHz, 8Ω)
Damping Factor	500
Input Sensitivity: Phono input	MM: 2.3 mV / 39 kohm MC: 250
Input Sensitivity: CD/LINE/RECORDER	220 mV / 13 kohm
Input Sensitivity: Power Amp input	1.1 V / 13 kohm
SN Ratio	PHONO (MM): 88dB PHONO (MC): 75dB CD: 107dB

Terminal

Phono Input	yes (MM/MC)
Ext. Pre Input (Power Amp Direct)	yes
Preout	yes
Audio (In/Out) Terminals *except Power Amp Direct In(or Ext-Pre) and Pre-out	6/1 (PHONO / MM&MC / CD / TUNER / LINE 1 / LINE 2 / RECORDER) * [PHONO] and [CD] inputs = high grade terminals.
Balanced XLR input	No
Rec-Out Selector	No
Optical input	No
Coaxial input	No
USB A	No
USB B	No
HDMI	No
DAC	No
2 sets of Spk Terminal	No
Speaker Terminal	Marantz Original SPKT-100+
Remote Control Bus Terminal	yes (Cinch)
NFC	No
Ethernet	No

Network

Engine	No
Computer music file streaming	No
Gapless Playback Music ServerUSB A	No
Internet radio	No
AirPlay 2	No
GoogleCast	No
Album art browsing	No
Jpeg Picture Playback	No
Cloud Music Service	No
WPS Wi-Fi Protected Setup	No
Wi-Fi Sharing	No
WMM	No
OFF mode	No
OFF mode	No
Multi-Poimt	No

UI

Display

yes (Porthole, OLED)

CONTROL

App Control via Network Player	yes
System Remote Controller	yes (New system remote controller to control SACD 30 and MODEL 30)
RS232C	No
Flasher Input	No
Trigger 12V	No
TV Auto-play (Opt/Coax digital-in sensor)	No

Others

Unit (W x H x D mm)	443 x 130 x 432
Packaging Dimensions (W x H x D mm)	534 x 255 x 522
Net weight	14.8kg
Packaging gross weight	17.6kg
Power Consumption	130W
at Standby	0.2W
at Network Control On (all of Bluetooth, Ethernet, Wi-Fi, USB)	No
AC Inlet	yes
AC Outlet	No
Owner’s Manual	Web Manual
Quick Start Guide	Paper
Chassis Material	SECC
Chassis Layer	Triple
Foot	New

Cosmetic

Panel Color	SG / BK
Front Center Panel	Aluminum
Back-shell	No
Side cover	Aluminum
Top cover	Steel
Edge-lighting	yes (Dimmer)
Volume Knob	Aluminum
Input Selector	Aluminum
Bass/Treble/Balance/ REC Out Sel knobs	REC Out–>PHONO (Aluminum)
Speaker A/B button	No
Power button	Aluminum
Other knob/button (LOUDNESS, SOURCE DIRECT etc)	No
Side screw	Copper plated
